The roller system is made of special and high density allow steel with superior hardness and high strength.
Our roller techonology guarantees equal product quality along the entire roll length - independent of the roller pressure. As a result, comprehensive and easily repeatable product qualities are achieved and in so doing boost productivity.
Good resistant to foreign pressure and temperature changes.
Suitable for high degree of fineness and tinting strength requirement.
Roller main driving axle made of double row self-aligning sperical roller bearing, during operation it can automatically align according to the roller axle ability, maintain the precision of the machine at all times.
Easy to operate.
Compact structure design.
Good fo ginding high viscosity and high fitness color product.
Application
Suitable for manufacturing of varnish, paint, dyestuff, ointment and cosmetic.
Model Specification
Model
TRM 225 (9")
TRM 300 (12")
TRM 400 (16")
Roller Diameter (mm)
300
305
406
Length of working surface (mm)
510
760
810
Speed of Roller - Small roller (rpm)
15.8
15.8
13.7
Speed of Roller - Medium roller (rpm)
47.4
47.4
42.3
Speed of Roller - Fast roller (rpm)
142
142
130.5
Main Motor Power (HP)
5.5
11
15
Machine Weight (kg)
1500
3000
4800
Overall Dimension (mm)
L1200xW1000xH1100
L1655xW1490xH1400
L2150xW1795xH1600
Length of Working Surface (mm)
300
305
406
*Data above provided for reference purpose only. Company reserve the right to change or modify any particular without prior notice.
